SketchUp Texture Mapping Decoded: The 4-Pin System, Projected Textures, and Curved Surface Fixes
Your brick wall tiles perfectly on the flat facade. Then it wraps around the curved bay window like a fever dream. Here is the complete fix.
Your brickwork looks right on every flat face. The mortar courses line up. The scale is correct. Then you orbit around the corner and the brick is sideways, enormous, or tiled in a completely different direction than the face next to it. You right-click, you click "Texture," and you stare at four coloured pins you have never touched before. This post is about those pins — what each one does, why curved surfaces need a completely different approach, and how to get your materials to behave like they live in the same building rather than four different dimensions.
Why SketchUp Textures Go Wrong (and It Is Not Your Fault)
When you drag a material from the Materials panel onto a face, SketchUp tiles the texture starting from the origin of the model's internal coordinate system. Not the corner of the face. Not the bottom edge. The model origin. This is why two adjacent faces with the same brick material often have brick courses that do not align — SketchUp is tiling from a global point, and each face just gets whatever portion of the tile lands on it.
The second thing to understand is that SketchUp distinguishes between flat surfaces and curved surfaces at a fundamental level. The Position Texture tool — the system that lets you adjust scale, rotation, and position — only works on flat faces. Cylinders, domes, and any surface created with Follow Me or Curviloft are a completely different problem that requires a different workflow.
Knowing these two facts before you start saves you an hour of frustration.
The 4-Pin System: Texture Edit Mode Explained
The official name is the Position Texture tool, but most users call it Texture Edit mode. To enter it, right-click any textured flat face and choose Texture → Position from the context menu. Four coloured pins appear on your texture. Each pin does something different, and which pin you drag determines the edit you are making.
SketchUp runs Texture Edit mode in two submodes. Understanding which one you are in is the key to not losing your mind.
Fixed Pin mode is the default. The four pins are coloured — red, green, blue, and yellow — each with a small icon.
Red pin (Move): Reposition the texture without changing scale or rotation. Use this to align a brick course to a window sill, or line up a wood-grain texture with the edge of a panel.
Green pin (Scale/Rotate): Scale and rotate the texture simultaneously around the red pin. Use this when the texture is the right design but wrong size and angle.
Blue pin (Scale/Shear): Scale along one axis while shearing. Useful for making a texture appear at an angle on a face.
Yellow pin (Distort): Pull one corner of the texture independently. Useful for perspective-correcting a photo texture on a non-rectangular face.
As Aidan Chopra notes in SketchUp For Dummies: "The Position Texture tool is actually more of a mode; we call it Texture Edit mode. Within this mode, you can be in either of two submodes."
Free Pin mode (Stretch Texture mode): right-click inside Texture Edit mode and uncheck Fixed Pins. Four white pins appear — each independently draggable. The texture stretches to fit wherever you place them. Use this for mapping a photo to exact corners of a face.
Pro tip: A fast way into Texture Edit mode: right-click a textured face → Texture → Position. Exit by pressing Enter or right-click → Done.
Watch out for: The Position Texture tool only works on flat faces. Curved surfaces need the Projected Texture workflow below.
Aligning Brick Courses Across Adjacent Faces
This is the most common texture problem on any architectural model — two adjacent walls with the same brick material where the mortar courses do not line up. The fix is straightforward once you know the trick.
Use Texture Edit mode (right-click → Texture → Position) to get the brick exactly right on the first face. Align the course to the ground plane, confirm the scale is correct, exit Texture Edit mode.
Select the Paint Bucket tool.
Hold Alt (Option on Mac) to switch to the Sample Paint cursor. Click the correctly positioned brick face to load its exact material and position.
Paint the adjacent faces. Because you sampled the material rather than selecting it fresh from the Materials panel, SketchUp carries the position data with it. The brick courses will align.
Best for: Walls meeting at corners, brick pillars adjacent to flat walls, wood cladding running continuous across a façade with reveals.
Curved Surfaces: Why the Normal Method Fails
SketchUp's documentation buries this three pages deep: you cannot use the Position Texture tool on curved surfaces. Chopra is explicit: "You can edit textures only on flat surfaces; the Position Texture tool doesn't work on curved surfaces."
A cylinder in SketchUp is not a true curve — it is a polygon made of multiple flat faces. When you apply a texture to a cylinder, each flat face tiles independently. This is why stone cladding on a circular column ends up with visible seams at every polygon edge. The solution is Projected Texture mode — it treats the texture as if projected from one direction, like a slide projector, rather than tiled face by face.
The Projected Texture Workflow for Curved Surfaces
Create a temporary flat face covering the curved surface from your desired texture view angle. A vertical rectangle placed against a cylinder works well.
Apply and position your texture on the flat face using normal Texture Edit mode. Get scale and position exactly right here — this is where all precision work happens.
Enable Projected mode: right-click the textured flat face → Texture → Projected. A check mark confirms it.
Sample and paint the curved surface: Select Paint Bucket, hold Alt (Option on Mac), click the projected flat face to load that projected material. Paint each face of the curved surface. The texture projects through from the flat proxy.
Once finished, delete the temporary flat face.
Pro tip: This workflow also works for Sandbox surfaces, Follow Me extrusions, and compound-curved geometry. It is the key technique for getting stone, wood, or cladding to look continuous across a complex form.
Watch out for: Projected textures work best when viewing is roughly perpendicular to the projection direction. For true all-angle coverage, extensions like WrapR or ThruPaint provide genuine UV unwrapping.
Using Make Unique Texture to Reduce File Size
Right-click any textured face and choose Make Unique Texture. SketchUp creates a cropped copy trimmed to exactly what is visible on that face. Chopra explains: "Context-click any textured face in your model and choose Make Unique Texture to create a copy of the texture you've selected and crop that copy according to the face it's on. Just because you can't see part of an image doesn't mean it's not there." Use before exporting renders or sending a model to a client.
When to Reach for a UV Plugin
SketchUp's built-in texture tools cover 90% of architectural use cases. But three situations push past them:
Organic meshes: Sculptural roofs, parametric façade panels, terrain with custom textures. Extensions like WrapR or SketchUV provide a proper UV editor to unfold the mesh and map textures with real UV coordinates.
Texture baking from renders: When applying a lighting-baked rendered image back to the model, UV mapping ensures correct projection.
Match Photo with complex geometry: For curved or irregular geometry, projection distorts. UV editing gives the control to correct it.
For most architectural production, native tools are sufficient. Reach for a plugin when geometry complexity makes the manual approach impractical.
A Quick Texture Checklist Before You Render
Scale check: Apply a grid material to verify real-world scale. Brick should look like brick, not mosaic tiles.
Projection check: Right-click each curved textured surface and confirm Texture → Projected is checked.
Alignment check: Orbit to corners and verify brick courses and wood planks align across adjacent faces. Fix with Sample Paint.
Make Unique Texture: Apply to any face using a large photo texture to reduce file size.
Purge unused materials: Materials panel → In Model → Purge Unused. Old material variants from texture editing accumulate silently.
Renderers are honest. Every stretched tile, misaligned course, and projection error that looks minor in the viewport will be visible in a final render. Fix at the model stage.
Conclusion
SketchUp's texture system is more powerful than most users realise, and more limited than the documentation makes clear. The 4-pin Position Texture tool gives you precise control over flat faces. The Projected Texture method — working through a temporary flat proxy — solves curved surfaces. Sample Paint with Alt carries exact texture positions from face to face to align courses and patterns.
The flat-versus-curved distinction is the thing to hold onto. Once you know which workflow applies to which geometry type, materials stop being a source of late-night panic and become something you can fix in a few deliberate steps.
